Drive+ N 12x
• Part NO. TLC-300-IP-12(NDI)
• 1/2.8 inch, 2.4MP CMOS Sensor
• 12X optical zoom
• Lens: f=3.92~47.32mm, F1.8~F2.8
• Horizontal View Angle: 72.5°(Wide)~6.3°(Tele)
• Vertical Viewing Angle: 42.72°~3.66°
• Diagonal Viewing Angle: 78.58°~7.42°
• Minimum Working Distance: 1.0m
• S/N Ratio: ≥50dB
Drive+ N 20x
• Part NO. TLC-300-IP-20(NDI)
• 1/2.8 inch, 2.4MP CMOS Sensor
• 20X optical zoom
• Lens: f=4.9~98mm, F1.5~F3.0
• Horizontal View Angle: 60°(Wide)~3.2°(Tele)
• Vertical Viewing Angle: 34.14°~1.12°
• Diagonal Viewing Angle: 67.08°~2.27°
• Minimum Working Distance: 1.0m
• S/N Ratio: ≥50dB
Video Format
HDMI:
1920*1080P60/50/30/25/59.94/29.97/24/23.98;
1920*1080I60/50/59.94;
1280*720P60/50/30/25/59.94/29.97
NDI®HX:
1920*1080@3~60;
1280*720@3~60;
1024*576@3~60;
640*360@3~60 (low bandwidth mode)
3G-SDI:
1920*1080P60/50/30/25/59.94/29.97/24/23.98;
1920*1080I60/50/59.94;
1280*720P60/50/30/25/59.94/29.97
USB 3.0:
1920*1080P60/50/30/25(USB 3.0);
1280*720P60/50/30(USB 3.0);
1280*720P25(USB 3.0&USB 2.0);
1024*576P30(USB 3.0&USB 2.0);
960*540P30(USB 2.0);
640*360P30(USB 2.0);
512*288P30(USB 2.0)
Image Parameters
• Noise Reduction: 2D&3D
• Minimum lux: 0.7Lux(50 IRE Max AGC, 1/30, F1.8)
• White Balance: ATW/Manual/Auto/Indoor/Outdoor/One Push/Sodium/Fluorescent
• Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
• Anti-Flicker: OFF, 50Hz, 60Hz
• Image Flip: Supported
• Mirroring: Supported
• Focus: Auto/Manual
• Iris: Auto/Manual
• Electronic-shutter: Auto/Manual
• Gamma: Supported
• Backlight Compensation: Supported
IP Streaming
• Video Encoding: H.264/H.265
• Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
• Bitrate Range: 1024Kbps~16384Kbps
• Network Port Speed: 1000M
• Protocol: NDI®HX, SRT, HTTP, RTSP, RTMP, DHCP, ONVIF, VISCA over IP, VISCA TCP, VISCA UDP, Pelco P/D, RTP Multicast, HTML
Pan/Tilt Movement
• Preset: Remote controller: 10; Serial port: 128; Accuracy: 0.1°
• Pan Rotation Angle: -170°~+170°
• Tilt Rotation Angle: -30°~+90°
• Pan Rotation Speed: 0.1°~120°/s
• Tilt Rotation Speed: 0.1°~80°/s
I/O Interface
• Control Port: RS232, RS485, NDI®HX, USB 3.0(UVC1.5), USB 2.0(UVC1.1)
• Video Port: NDI®HX, HDMI, 3G-SDI, USB 3.0
• Tally: Supported
• POE+: Supported
• Daisy Chain: Supported
General
• Input Voltage: DC12V, POE+(IEEE802.3at)
• Operating Temperature: -10℃~50℃
• Operating Humidity: ≤80%
• Dimension(L×W×H): 220mmx190mmx173mm
• Net Weight: 1.35kg
• Color: Black/White
