Camera
• Part NO. TLC-100-U2-4K
• 1/2.8 inch, 12MP UHD CMOS sensor
Lens
lris: F1.8;
View Angle: 80°(Diagonal), 65°(Horizontal)
Object Distance: 10cm ~ infinity
Zoom
1080P supports 2X digital zoom,
720P supports 3X digital zoom
• EPTZ: Supported
• Output Interface: USB(Type-C)
• Focus: Al Auto Focus
Image Parameters
• White Balance: Auto/Manual
• Exposure: Auto/Manual
• Flicker: 50HZ/60HZ/OFF
• 2D、3D Noise Reduction: Supported
• WDR: Supported
• Backlight Compensation: Supported
• Mirror, Flip: Supported
• Microphone Pointing: Omnidirectional microphone
• Sensitivity: -26+2dB RL=2.2KQ Vs=2.0V
• S/N Ratio: 64dB
Video Format
YUY2:
1280*720@10；
1024*576@20；
640*480@30
MJPG:
Landscape video:
3840*2160@30；
2560*1440@30；
1920*1080@60:
1920*1080@30；
1280*720@30；
1024*576@30；
640*480@30
Portrait video:
1080*1920@30；
720*1280@30；
576*1024@30；
360*480@30
General
• Polar Distance: 3~5m
• Input Voltage: USB power supply
• Working Environment: Temperature: -10℃~50℃; Humidity: ≤80%
• Webcam Size: 76mmxф48mm
• Package Size: 114.5mmx87mmx85mm
• Net Weight: 0.2kg
• Gross Weight: 0.4kg
• Available Color: Dark gray, Silver
• Accessories: 1.5m USB 2.0(A-C) cable, Manual, Warranty card
