Image Parameters
• Noise Reduction: 2D&3D
Minimum lux:
20X: 0.5Lux(50 IRE Max AGC, 1/30, F1.8)
30X: 0.5Lux(50 IRE Max AGC, 1/30, F1.8)
• White Balance: Auto/Manual/ATW/Push/
Indoor/Outdoor/
Color Temperature
• Exposure: Auto/Manual/Shutter Priority/Iris Priority/Brightness Priority
• Anti-Flicker: OFF, 50Hz, 60Hz
• Image Flip: Supported
• Mirroring: Supported
• Focus: Auto/Manual
• Iris: Auto/Manual
• Electronic-shutter: Auto/Manual
• Gamma: Supported
• Backlight Compensation: Supported
IP Streaming
• Video Encoding: H.264/H.265
• Bitrate Control: Variable bitrate(VBR), Constant bitrate(CBR)
• Bitrate Range: 1024Kbps~122800Kbps
• Network Port Speed: 1000M
• Protocol: NDI®HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP(TCP&UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC
Pan/Tilt Movement
• Preset: Remote controller: 10; Serial port: 256; Accuracy: 0.1°
• Pan Rotation Angle: -170°~+170°
• Tilt Rotation Angle: -30°~+90°
Pan Rotation Speed:
20X: 0.1°~120°/s
30X: 0.1~80°/s
Tilt Rotation Speed:
20X: 0.1°~80°/s
30X: 0.1°~60°/s
I/O Interface
• Control Port: RS232(RS485), NDI®HX3
• Video Port: NDI®HX3, HDMI, 3G-SDl, USB Type-C
• Audio Port: stereo 3.5mm linear inputs
• Tally: Supported
• POE+: Supported
• Daisy Chain: Supported
General
• Input Voltage: DC12V, POE+(IEEE802.3at)
• Operating Temperature: -10℃~50℃
• Operating Humidity: ≤80%
Dimension(L×W×H):
20X: 220mmx190mmx173mm
30X: 220mm×190mm×193.5mm
Net Weight:
20X: 1.5kg(3.3LBS)
30X: 1.9kg(4.2LBS)
• Color: Black/White
